Finescale Bespoke Track and Pointwork for over 25 years. Bullhead or Flatbottom and Narrow, Standard or Broad gauges.

Timbering:- ABS Plastic, Plywood, Thick or Thin - Copperclad Soldered Construction Pointwork can also be supplied.

Rail:- UK practice -Flat Bottom (Code 143 with Peco Pandrols) or Bullhead - Code 125, HiNi, Steel or Nickel Silver - Peco Code 124 Nickel Silver rail and chairs also possible.

For Bullhead Track, Chairs Exactoscale. Special chairs used where available and appropriate at additional cost. Peco Pandrols for Flatbottom code 143 (C&L chairs add 50% due to extra cost)

DCC Friendly.

All rivet construction can be chosen for plywood timbering with cosmetic chairs but at an additional cost depending on the type of turnout specified.

Soldered common crossing.

Droppers fitted.

Choice of Stretcher bars but my preference is currently Ambis.

Switch anchor stays can also be fitted (where appropriate i.e. REA/GW type flexible switches) at extra cost, as can additional detailing.

Pointwork complexes and layouts can also be designed and/or produced. However I can’t perform the impossible and if it won’t fit, it won’t fit. Equally, there may be instances where an unlikely formation is the only answer, e.g. double outside slips are not found on main lines (unless someone can tell me differently of course) but usually in locations tight for space such as yards, however if you need to have one on your main line, you should be aware of this and either accept it or revise your plans accordingly.

In addition to REA/GW flexible switches - Older style curved and loose heel switch turnouts are also possible and can be substantial space savers.

Plain track can also be supplied, please specify type of chair and panel length, Priced at the equivalent of £37.50 per half metre.

3D printing of trackwork is coming soon but I don't offer it as a solution just yet as there is uncertainty in my mind as to its durability especially outdoors and not all prototype chairs and formations are easily catered for.

In 0 gauge you have the choice of various standards but only 0-MF (31.5mm gauge) will allow the smooth passage of standard finescale wheelsets, without resorting to alterations. 0-SF (31.2mm) and 0-XF (31.0mm) will also achieve this but back to back, minimum radii and gauge widening may need to  be taken into consideration. Standard 0-F (32mm), will of course run everything but with the finer scale wheels of today may be a bit bumpy through the common crossing, especially with flatter angle crossings, as they tend to fall into the gap.

Of course you can also go for S7 (33mm) which is the 7mm scale equivalent of P4 and you will probably have to rewheel/alter everything. It does look very good though.

In the smaller scales you have the choice of P4, EM various versions of 00 plus the narrow gauge and wider gauge variants.

Just a note for those interested in comparing point kit prices with my Bespoke built ones, have a look at their kit prices! They can include items that you really only need to buy once

Please note that any request for bullhead trackwork built from C & L components will now carry a 50% surcharge eiither 4mm or 7mm scale. The main reason is that at the time of writing the chairs and rail are so expensive, for instance, according to his website a bag of 7mm scale 500 chairs now costs £51.60. Exactoscale equivalent 3 bolt is £29.00 Permaway is similar - at least for the time being.

For further information please contact me:stephen@trackandsignals.co.uk

Indication Prices in GBP
Turnout 4m scale 7mm scale 2mm scale
Catch Point 24.00 30.00 19.20
A5 68.00 85.00 54.40
A6 68.80 86.00 55.04
B6 70.40 88.00 56.32
B7 73.60 92.00 58.88
B8 76.80 96.00 61.44
C9 80.00 100.00 64.00
C10 84.00 105.00 67.20
D11 88.00 110.00 70.40
E12 92.00 115.00 73.60
F13 108.00 135.00 86.40
1 in 4 diamond 64.00 80.00 51.20
1 in 5 Diamond 65.60 82.00 52.48
1 in 6 Diamond 67.20 84.00 53.76
1 in 7 Diamond 68.80 86.00 55.04
1 in 8 Diamond 70.40 88.00 56.32
1 in 9 Diamond 72.00 90.00 57.60
1 in 6 Single Slip 136.00 170.00 108.80
1 in 7 Single Slip 140.00 175.00 112.00
1 in 8 Single Slip 141.60 177.00 113.28
1 in 9 Single Slip 143.20 179.00 114.56
1 in 6 Double Slip 143.20 179.00 114.56
1 in 7 Double Slip 144.80 181.00 115.84
1 in 8 Double Slip 147.20 184.00 117.76
1 in 9 Double Slip 148.80 186.00 119.04
3 way Tandem A6/B6 128.00 160.00 102.40
3 way Tandem A6/B7 129.60 162.00 103.68
3 way Tandem A6/B8 131.20 164.00 104.96
3 way Tandem A6/B9 136.00 170.00 108.80
3 way Tandem A6/C9 144.00 180.00 115.20
3 way Tandem B6/B8 148.00 185.00 118.40
3 way Tandem B6/B9 152.00 190.00 121.60
3 way Tandem B6/C9 160.00 200.00 128.00
3 way Tandem B7/B9 164.00 205.00 131.20
3 way Tandem B7/C9 168.00 210.00 134.40
3 way Tandem B7/C10 176.00 220.00 140.80
3 way Tandem B8/C10 180.00 225.00 144.00
4 way from 320.00 400.00 256.00
5 way from 360.00 450.00 288.00
